WDM-MS401 electric lead seals meter security tags

WDM-MS401  electric lead seals meter security tags

Name：electronic security water meter lead seal

Applications:   Meters (water / gas / electric / electronic) Tankers, tube equipments, valves,

electric meter,water meter, gas tank, container, postal truck, trailer, parcel heavy-duty boxes and cases, luggage box, first aid kit,meter boxes of water works, electric power, oil gas industry, etc.
Specification:   Plastic part: Polycarbonate
                         Metallic spiral wire: galvanized wire or stainless steel wire etc
The wire can be supplied separately or attached at the seal itself.
The external part is transparent for the visual control of integrity
Installation:  Pass wire through two holes in the plastic part, and then turn the handle to the right to achieve perfect closure, the handle must be broken
Removable by cable cutters
Printing :   Company logo and/or name, sequential number ,Bar code is available
Colors :    Body: transparent
                   Insert: yellow, blue, white, green, orange, red, etc
Packaging
Standard Packaging: 2000PCS
ton Dimensions: 35cm X25cm X 27cm
Carton Weight: Gross: 4.0 kg

Features

1. The PC transparent cover can be seen to check the integrity of the locking and locking process
2. High impact ABS will provide great strength and durability
3. The shell adjusts the locking position and has a good anti-pry function
4. Laser printable permanent logo

- Inlet for a cable of a special form for the elimination of manipulations;
- Thickened body of the seal for use at various facilities;
- The rotor is recessed deep into the body of seal to protect it;
- The body of seal is transparent enough to control integrity, but complicates attempts during manipulation.
- The unique rotor mounting mechanism in the body of seal protects against manipulation;
- Reliable 4-petal ratchet mechanism, prevents reverse rotation;
- Laying the cable in an individual groove (place) for better cable distribution and to avoid layering;
- Special design of seal for maximum cable tension on the object.
